Leveller GT-250DKH · GT-275DKH · GT-300DKH

Presentation

The GT-250DKH, GT-275DKH and GT-300DKH levellers are the top models of Fransgård's lift-suspended levellers. They have all the same great advantages as the GT-DK version.

Here you get a leveller that always gets down into the road material and easily makes a road slope, so water easily runs off the road.

Details that enhance quality

GT-DKH sets a new standard in professional cutting. The icing on the cake is the 3-point suspension design, where the horizontal angle is set up to 20° to each side between boom and hitch, thereby not stressing the lift arms on the tractor. This reduces wear and thus costs.

Mounting bracket for hydraulic cylinder and wear steel for the blade are made of Hardox 500. Heavy reinforcements on the back and on the side of the blade. On the side of the blade there are holes for mounting the snow blade and side plates.

The back of the blade is designed to push excess material into the road by backing up the blade without turning it - a great advantage when approaching an asphalt road, for example.

Slide title

Write your caption here

Button
Slide title

Write your caption here

Button
Slide title

Write your caption here

Button
Slide title

Write your caption here

Button
Slide title

Write your caption here

Button
Slide title

Write your caption here

Button

Technical data:

Model:	GT-250DKH	GT-275DKH	GT-300DKH
Working width	250 cm	275 cm	300 cm
Blade height	70 cm	70 cm	70 cm
Mechanical offset adjustment, right/left	60 cm	60 cm	60 cm
Hydraulic rotating blade	244°	244°	244°
Horizontal adjustment hydraulic	20°/20°	20°/20°	20°/20°
Hydraulic connectors	3 double	3 double	3 double
Reversible wear steel Hardox 500	Std.	Std.	Std.
Push/front mounting	Yes	Yes	Yes
Support wheels	Std.	Std.	Std.
Snow blade, right	Possible	Possible	Possible
Side flap	Possible	Possible	Possible
3-point suspension	Cat III	Cat III	Cat III
Weight	940 kg	955 kg	975 kg
Tractor performance	Max. 150 HP	Max. 150 HP	Max. 150 HP

Details:

Blade rear

Strong blade with reinforcements both at the top and at the back of the blade.
Button
Blade rear, beveled edge

The lower reinforcement at the rear is designed so that you can reverse with the leveller without turning the blade, and you will be able to reverse over any excess material that the leveller will press and distribute into the road, for example, when you come to an asphalt road.
Button
Hydraulic cylinder, horizontal

The 3-point suspension has a standard hydraulic cylinder for adjusting the horizontal cutting angle. You can set it up to 20 degrees both to the right and left side.
Button
Top bar attachment

The top bar attachment also has both a fixed hole and an elongated slot, where you can advantageously mount the top bar bolt when, for example, levelling roads, the leveller will follow the terrain better and you will achieve a better end result.
Button
Blade ends

Reinforced ends on the blade of the leveller, which are also prepared for mounting the side flap, snow blade and blade extension kit.
Button
Wearing steel mounted

Reversible wear steel bolts on with 16mm steel bolts grade 12.9.
Button
Wheels

The leveller comes as standard with large wheels that are stepless adjustable via a spindle. The wheels can turn 360 degrees, so you can reverse with the leveller without turning the blade.
Button
Support legs

Support legs are easily placed in the holder, so you always have them with you when you need to park the leveller again.
Button
Bolts, offset adjustment

The leveller can be mechanically offset adjusted to the right or left side.
The locking bolt is mounted without using tools. All locking bolts are galvanised.

Button
Turntable

The heavy-duty turntable on the blade is bolted together and has a replaceable PETP plastic wear disc and lubrication nipples to avoid wear in the turntable.
Button
Wearing steel all

The leveller is fitted as standard with reversible smooth/toothed wear steel. You can have your leveller delivered with a smooth or toothed wear steel at no extra cost if this is specified when ordering the leveller.
The leveller can also be fitted later with one of the other types of wear steel.

Button
Blade cylinder

A strong blade cylinder with 45 mm stick ensures that the blade is kept stable.
The cylinder is well protected on top of the boom.

Button
Turning radius

The GT-DK leveller can be hydraulically turned up to 244 degrees.
Button
3-point cat III

3-point suspension is standard Cat. III.
Button
Cylinder attachment

Heavy duty cylinder hinge in special steel provides stable operation and long life.
Button
Fitting for hydraulic offset adjustment

The leveller is prepared for the installation of hydraulic offset adjustment item no. 2528.
Button
Hydraulic hose holder

The leveller is fitted with a holder for the hydraulic hoses as standard.
Button
3-point suspension, rear

The 3-point suspension has a guide bolt at the rear with a hardened bush that can be greased.
Button
Degreemeter

The leveller is fitted with a degreemeter that is clearly visible from inside the tractor.
Button

Optional extras:

Item No. 2532

Hydraulic cylinder for adjusting the right wheel; requires 1 double-acting hydraulic connector.
Button
Item No. 2528

Hydraulic offset adjustment can shift the blade up to 55 cm to the right or left side, so you don't have to drive with the tractor wheel in the ditch, for example.
The hydraulic cylinder allows the blade to have offset adjustment exactly to the required distance if space is at a premium.

Button
Item No. 2517-2520

Rubber blade for mounting on all Fransgård models of levellers. The rubber blade is mounted behind the existing wear steel, which acts as a backstop on the rubber blade. It should be fitted 2-3 cm lower than the wear steel and can be continuously moved downwards as it wears down.
You drill the holes in the rubber blade, which is mounted with the bolts provided.
Button
Item No. 2530

Side flap to hold the material. Can be mounted on both the right and left side.
Button
Item No. 2530

All Fransgård's newer levellers are ready for mounting side flaps that are easily mounted with the 3 bolts provided.
Button
Item No. 2546

Snow blade for the right side, cut the snow edge diagonally so that it does not collapse and fall behind the tractor where you have just driven.
Button
Item No. 2546

All Fransgård's newer levellers are ready for mounting snow blades and are easily mounted with the 3 bolts provided.
Button
Item No. 2543

Shock valve with an accumulator for mounting on the blade cylinder of all Fransgård hydraulic levellers.
Button
Item No. 2543

The shock valve will relieve the cylinder and the leveller when hitting objects and minor impacts, in both the right and left side of the blade. Supplied as a complete set with assembly instructions.

Button
Item No. 2544

Shock valve for mounting on the blade cylinder of all Fransgård hydraulic levellers.
The shock valve will relieve the cylinder and the leveller when hitting objects and minor impacts, in both the right and left side of the blade. Supplied as a complete set with assembly instructions.
Button
Item No. 2549

Adjustable side flap with mechanical adjustment so the side plate is always perpendicular to the direction of travel.
Button
Item No. 2549

The side flap has adjustable wear steel.
Button
Item No. 2550

Extension set 2 x 25 cm for GT-300DKH blade incl. Wear steel.
Button
Item No. 2550

It is bolted to the blade, after which the total width of the blade is 350 cm.
Button
Item No. 2529

3-point suspension is standard cat. III - when ordering item no. 2529, the suspension will be with cat. II/III. This option cannot be retrofitted and must therefore be ordered together with the leveller.
Button
Item No. 2542

EL-Hydraulic control of the hydraulics of the leveller. The control requires 12 volts and 1 double acting hydraulic connector.
